Power:
360 W (sustained), 550 W (peak)
|
Power:
500 W (sustained), 700 W (peak)
|
Torque:
13.5 Kg-cm (32 Kg-cm max).
|
Torque:
20 Kg-cm (42 Kg-cm max).
|
Shaft speed:
2500 RPM (3600 RPM max)
-With planetary gearing, 9.33:1 reduction = ~268 RPM
|
Shaft speed:
2500 RPM (3600 RPM max)
-With planetary gearing, 9.33:1 reduction = ~268 RPM
|
Current input strength rating:
16.5 Amperes.
|
Current input strength rating:
24 Amperes.
|
Efficiency (conservative): 85-90%
-dyno-test claims as high as 97.6%
|
Efficiency (conservative): 85-90%
-dyno-test claims as high as 97%
|
Weight:
1.8 Kg (2.7 with gear module)
|
Weight:
2.1 Kg (3.1 with gear module)
|
Size:
--82 mm L, (107 L incl. shaft), with 90 x 90 mm base mounting.
Size with gear module:
--107 mm L, (154 L incl. shaft), with 90 x 90 mm base mounting.
|
Size:
--82 mm L, (107 L incl. shaft), with 90 x 90 mm base mounting.
Size with gear module:
--117 mm L, (164 L incl. shaft), with 90 x 90 mm base mounting.
|
Shaft Size (without gear module):
--12 mm D with 2 flat surfaces
Shaft Size (with gear module):
--20 mm D (available with or without key-way)
|
Shaft Size (without gear module):
--12 mm D with 2 flat surfaces
Shaft Size (with gear module):
--20 mm D (available with or without key-way)
|
